MEMRECAM GO-4K
Smart High Speed Camera System
Smart High Speed Camera for Automotive / Military / Academic / Industry / R&D / Testing
A compact, lightweight high speed 4K camera system for limited space installations
Full resolution 4608 x 2176 pixels
1,000 FPS at 4K Resolution
- Up to 20,000 fps at reduced resolutions
Compact & lightweight
- 128 x 128 x 135 mm / 2.9 kg
Easy control
- Control via mobile device or PC
Battery powered for flexible operation
Additional Product Details
Overview
Our new 4K model of the MEMRECAM GO series: the GO-4K Smart High Speed Camera, is equipped with a 10-megapixel high-definition sensor on a new technology platform and delivers 1,000 fps at 4608×2176 pixels. Keeps high image quality in wide-field-of-view shooting which improves the accuracy of image analysis. Portable and easy install compact and lightweight body (128 x 128 x 135 mm, weight 2.9 kg) enables capturing high speed phenomena in scenes.
Features
Compact & Light Weight
Compact and light weight camera body at 128×128×135mm - 2.9kg for easy installation in locations with limited space, usable in various research fields
Easy Operation
Camera can be controlled from a mobile device or PC via web browser without the need for dedicated control software
*Wi-fi router is required
Easy Connector Access
Connector for synchronization with existing camera models
Outdoor Use & Narrow Spaces
- Perfect for applications where there is no power
- Instantly powers on without the need for cables, minimizing set up
Battery Operation
- Supports IDX batteries
- Simple cabling without AC Power
Data Saves to SSD
- PC-less operation
- Easy to adjust imaging view with your smartphone or tablet
Specifications
| Sensor | 10 Megapixel, CMOS |
|---|---|
| Active Pixel | 4,608 x 2,176 |
| ISO (REI) | ISO 100~3,200 (color) ISO 400~12,500 (mono) |
| Electric Shutter | 1/10~1/909,000 sec |
| Memory | 16GB / 32GB / 64GB |
| Bit Depth | Sensor Output 10/12bit * Switches automatically according to chosen fps Recording 12bit |
| Interface | 1000BASE-T / USB 3.1 / USB 2.0 |
| Canera Control | Mobile device / PC |
| Power | 13-32V DC |
| Dimensions (WxHxD) | Approx. 128 × 128 × 135mm (excluding protrusions) |
| Weight | Approx. 2.9kg |
Frame Rate / Resolution
| (fps) | Pixel (H) X (V) |
Recording Time * in sec |
|---|---|---|
| 1,000 | 4,608 x 2,176 | 2.26 |
| 2,000 | 4,608 x 1,056 | 2.33 |
| 3,000 | 4,608 x 672 | 2.44 |
| 4,000 | 4,608 x 480 | 2.57 |
| 5,000 | 4,608 x 352 | 1.80 |
| 6,000 | 4,608×288 | 2.85 |
| 10,000 | 4,608×128 | 3.85 |
| 16,000 | 4,608×64 | 4.82 |
| 20,000 | 4,608×32 | 7.71 |
* Recording Time with 32GB memory at 10-bit recording
Options
TBA
